Spatial Provinces and Domains of the Central Valley for Textural Analysis

Metadata Updated: November 12, 2020

This digital dataset contains the 9 major areas used to subdivide the Central Valley for the interpolation of the percentage of coarse-grained deposits into the texture model. This texture model was used as input data for the hydraulic properties portion of the Central Valley Hydrologic Model (CVHM). The Central Valley encompasses an approximate 50,000 square-kilometer region of California. The complex hydrologic system of the Central Valley is simulated using the USGS numerical modeling code MODFLOW-FMP (Schmid and others, 2006). This simulation is referred to here as the CVHM (Faunt, 2009). Utilizing MODFLOW-FMP, the CVHM simulates groundwater and surface-water flow, irrigated agriculture, land subsidence, and other key processes in the Central Valley on a monthly basis from 1961-2003. The total active modeled area is 20,334 square-miles on a finite difference grid comprising 441 rows and 98 columns. Slightly less than 50 percent of the cells are active. The CVHM model grid has a uniform horizontal discretization of 1x1 square mile and is oriented parallel to the valley axis, 34 degrees west of north (Faunt, 2009). In order to better characterize the aquifer-system deposits, lithologic data from approximately 8,500 drillers' logs of boreholes ranging in depth from 12 to 3,000 feet below land surface were compiled and analyzed. The percentage of coarse-grained sediment, or texture, then was computed for each 50-foot depth interval of the drillers' logs. A 3-dimensional texture model was developed by interpolating the percentage of coarse-grained deposits onto a 1-mile spatial grid at 50-foot-depth intervals from land surface to 2,800 feet below land surface. The CVHM is the most recent regional-scale model of the Central Valley developed by the U.S. Geological Survey (USGS). The CVHM was developed as part of the USGS Groundwater Resources Program (see "Foreword", Chapter A, page iii, for details).

Access & Use Information

License: No license information was provided. If this work was prepared by an officer or employee of the United States government as part of that person's official duties it is considered a U.S. Government Work.

Downloads & Resources

Dates

Metadata Date August 24, 2012
Metadata Created Date November 12, 2020
Metadata Updated Date November 12, 2020
Reference Date(s) January 1, 2012 (publication)
Frequency Of Update notPlanned

Metadata Source

Harvested from DOI Open Data

Graphic Preview

Illlustration of data set

Additional Metadata

Resource Type Dataset
Metadata Date August 24, 2012
Metadata Created Date November 12, 2020
Metadata Updated Date November 12, 2020
Reference Date(s) January 1, 2012 (publication)
Responsible Party U.S. Geological Survey (Point of Contact)
Contact Email
Guid
Access Constraints Use Constraints: Data have been checked to ensure the accuracy of the data. If any errors are detected, please notify the originating office. The U.S. Geological Survey strongly recommends that careful attention be paid to the metadata file associated with these data. The U.S. Geological Survey shall not be held liable for improper or incorrect use of the data described and (or) contained herein. Acknowledgement of the U.S. Geological Survey would be appreciated in products derived from these data. Any use of trade, product, or firm names is for descriptive purposes only and does not imply endorsement by the U.S. Government. Although this Federal Geographic Data Committee-compliant metadata file is intended to document the dataset in nonproprietary form, as well as in ArcGIS format, this metadata file may include some ArcGIS-specific terminology., Access Constraints: None.
Bbox East Long -118.472608
Bbox North Lat 40.702574
Bbox South Lat 34.889516
Bbox West Long -122.641382
Coupled Resource
Frequency Of Update notPlanned
Graphic Preview Description Illlustration of data set
Graphic Preview File https://water.usgs.gov/GIS/browse/pp1766_cvhm_texture_regions.png
Graphic Preview Type png
Licence Although these data have been used by the U.S. Geological Survey, U.S. Department of the Interior, no warranty expressed or implied is made by the U.S. Geological Survey as to the accuracy of the data. The act of distribution shall not constitute any such warranty, and no responsibility is assumed by the U.S. Geological Survey in the use of these data, software, or related materials. The use of firm, trade, or brand names in this report is for identification purposes only and does not constitute endorsement by the U.S. Geological Survey. The names mentioned in this document may be trademarks or registered trademarks of their respective trademark owners.
Metadata Language
Metadata Type geospatial
Progress completed
Spatial Data Service Type
Spatial Reference System
Spatial Harvester True
